1.Electric drived, Flexible operation, no noise, no pollution.
2.Adopting advanced world famous brand components in hydraulic parts ,electric parts and operation parts.
3.Double driving efficiency.
4.Pothole guards and tilt level sensor to guarantee operators’ safety.
5.Emergency stop to avoid potential danger.
1.Electric drived, Flexible operation, no noise, no pollution.
2.Adopting advanced world famous brand components in hydraulic parts ,electric parts and operation parts.
3.Double driving efficiency.
4.Pothole guards and tilt level sensor to guarantee operators' safety.
5.Emergency stop to avoid potential danger.
| Model | APTIMOS-04E | APTIMOS-05E | APTIMOS-06 |
| Measurements | |||
| Max. Working Height-A | 18.37 ft | 20.67 ft | 25.59 ft |
| Max. Platform Height-B | 11.81 ft | 14.11 ft | 19.03 ft |
| Overall Length(with Ladder)-C | 5.02 ft | 5.02 ft | 6 ft |
| Overall Width-D | 2.49 ft | 2.66 ft | 2.49 ft |
| Overall Height(Rails down)-E | 5.41 ft | 5.74 ft | 6 ft |
| Platfom size(L*W)-F | 4.43*2.29 ft | 4.43*2.29 ft | 5.35*2.29 ft |
| Extension Size-G | 1.97 ft | 1.97 ft | 2.95 ft |
| Wheel Base | 3.67 ft | 3.67 ft | 4.33 ft |
| Min. Clearance(Stowed) | 0.16 ft | 0.16 ft | 0.26/0.18 ft |
| Min. Clearance(Raised) | 0.065 ft | 0.065 ft | 0.065 ft |
| Performance | |||
| Platform Capacity | 529 lbs | 507 lbs | 507 lbs |
| Extension Capacity | 249 lbs | 249 lbs | 249 lbs |
| Max. Occupancy | 2 | 2 | 2 |
| Drive speed(stowed) | 2.48mile/h | 2.48mile/h | 2.48mile/h |
| Drive speed(Raised) | 0.31mile/h | 0.31mile/h | 0.5mile/h |
| Min. Turning Radius (In.) | 0.98 ft | 0.98 ft | 0 ft |
| Min. Turning Radius (Out.) | 4.92 ft | 4.92 ft | 5.08 ft |
| Up/Down Time | 25/25s | 25/20s | 16/34s |
| Gradeabilty | 25% | 25% | 25% |
| Max. Slope | 1.5°/3° | 1.5°/3° | 1.5°/3° |
| Control | Switching | Switching | Proportional |
| Drive | FWD | FWD | FWD |
| Multi Disc Brake | Rear | Rear | Front/Rear |
| Tires(mm) | 230*80 | 230*100 | 305*102 |
| Power | |||
| Batteries(V/Ah) | 2*12/85 | 2*12/85 | 4*6/200 |
| Charger | 100-240VAC/15A | 100-240VAC/15A | 100-240VAC/30A |
| Weight | |||
| Weight | 1940 lbs | 2174 lbs | 3468/3439 lbs |
